The Ultimate Lab Rack

Ultimate CCNA CCNP & CCIE R&S Cisco Lab Training Kit

What's Included?

The Ultimate in Cisco Networking Technology, This Lab does Everything! Too Many Features to List!




Features Of This Package

3 x 2801 - 15.1 IOS Advanced Enterprise Integrated Services Router 256D/64F

3 x 3745 - High Performance Router Dual Fast Ethernet - Enterprise & Security Feature Set

3 x 2610XM - 12.4T IOS 64D/32F Router - Advanced IP Feature Set

4 x 2610 - Basic IP Router

1 x 3700 WAN Switch - 16 Port Frame Relay / MPLS Switch

4 x NM-4T - Four Port 2-8Mbps Serial Interface Module

1 x WS-C3560-24PS-S - Advanced Layer 3 IP Services Switch

2 x WS-C3550-24-SMI - Layer 3 IP Switch with EMI Image

4 x WS-C2950-24 - Enhanced IOS Ethernet Switch - RSTP / Port Security

10 x WIC-1DSU-T1 (V1&V2) - T1 WAN Interface Card

10 x WIC-1T - Serial WAN Interface Cards

1 x 48U - 7 Ft Open Network Rack

10 x DB60 to DB60 Serial DTE/DCE WAN Emulation Cables

5 x T1 Crossover WAN Emulation Cable

20 x Cat 5 Network Cables (XOvers Included)

21 x Power Cords

1 x Powder Blue Cisco Console Cable



14 Perfect Condition Routers that run Everything From VPN to CME to IPV6 to MPLS and more

36 Serial WAN Ports from 64Kbps to 8Mbps

6 Immaculate Ethernet Switches that cover All aspects of Spanning Tree including

Multi-Layer Switching, Gigabit Ethernet, Complex 802.1q and VTP

Modules / Network Interface Cards / Cables and Connectors, ITS ALL INCLUDED!

3560 Layer 3 Switch with Advanced IP Services IOS

FULL 7 FOOT Commercial Grade NETWORK RACK and Accessories!

Frame Relay & MPLS WAN Switch


220,000 Packet Per Second

16 Ports - Up to 8Mbps per port (NM-16A/S or NM-8A/S 128Kbps per port)


Proper Network Topology


Matches INE and IP Experts Topology Exactly PLUS UPGRADES


3745s 220K PPS vs. 1841s 80K PPS

2600s with no transceiver (2500s are slow)

220K PPS WAN Switch with MPLS, 2522 is 4K PPS no MPLS

More Devices, Serial Ports, and Cables for increased and more complex topologies
